| P/N | PS-TPD-0600NNFAGU-1 |
|---|
| WATTS | 600W |
|---|
| RGB FAN | No |
|---|
| FORM FACTOR | ATX |
|---|
| MODEL | SP-600AH2NCG |
|---|
| TYPE | ATX 12V v2.4 and EPS v2.92 |
|---|
| MAX. OUTPUT CAPACITY | 600W |
|---|
| PEAK OUTPUT CAPACITY | 720W |
|---|
| DIMENSION ( W / H / D ) | 150mm(W) x 86mm(H) x 140mm(D) |
|---|
| PFC (POWER FACTOR CORRECTION) | Active PFC |
|---|
| POWER GOOD SIGNAL | 100-500 msec |
|---|
| HOLD UP TIME | > 12msec at 80% of full load |
|---|
| INPUT CURRENT | 9A max. |
|---|
| INPUT FREQUENCY RANGE | 47Hz - 63Hz |
|---|
| INPUT VOLTAGE | 100V – 240V~ |
|---|
| OPERATING TEMPERATURE | 0°C to + 40°C |
|---|
| OPERATING HUMIDITY | 20% to 90%, non-condensing |
|---|
| STORAGE TEMPERATURE | -20°C to + 70°C |
|---|
| STORAGE HUMIDITY | 5% to 95%, non-condensing |
|---|
| COOLING SYSTEM | 12cm fluid dynamic bearing fan |
|---|
| EFFICIENCY | Meet 80 PLUS®Gold at 115Vac input. |
|---|
| MTBF | 100,000 hrs minimum |
|---|
| SAFETY APPROVAL | CE/cTUVus/TUV/FCC/BSMI/EAC/S-Mark |
|---|
| PCI-E 6+2PIN | 2 |
|---|
